Small piles with a large time span: Whether as short-term piles or permanent piles - we offer you the right model for your requirements. Choose between simple (EKS) or additional (DKS) corrosion protection!
PROPERTIES OF THE BBV MICROPILES
The BBV micropile is approved by the building authorities for the bearing member diameters 28, 32, 40 and 50 mm (approval Z-32.1-7) as reinforcing steel bars with threaded ribs made of B500B, and for the bearing member diameters 57.5 mm and 63.5 mm (approval Z-34.14-207) as steel bars with threaded ribs made of S 555/700.
Depending on the service life as a short-term or permanent pile, production is either with single (EKS) or factory-applied additional corrosion protection (DKS).
Can optionally be equipped with post grouting systems.
MICROPILE WITH EKS
(SHOWN HERE AS A TENSION POLE)
MICROPILE WITH DKS
(SHOWN HERE AS A TENSION POLE)
Socket joints
